Road Traffic Index Line Remove Machine Road Marking Removal Cleaning Machine

  • Introduction
Introduction

Concrete Milling Machine RWXB22

https://membercenter.made-in-china.com/productmanage.do?xcase=view&prodId=IfjRclFHHVYJ&queryGroupId=&queryCatCode=&pageSize=30&queryState=3&prodUpgradeActivity=

Product Description

Used for milling and cleaning of hot-melt or cold spray road markings, as well as for milling groove operations before embedded road marking spraying.
This machine is specially designed by Roadway for highway marking construction, integrating multiple new technologies to achieve integrated construction of milling, strong rolling brush cleaning, negative pressure recycling, and waste storage. It can be completed in one operation, thoroughly cleaned, and has high work efficiency.
The scientific design of milling mechanism has the following three characteristics:
1. The milling drum works with the road slope to achieve uniform milling depth;
2. The milling accuracy is high and can be controlled within 0.2mm.
3. The marking paint does not stick to the knife and does not require frequent cleaning.


road traffic index line remove machine road marking removal cleaning machine-1微信图片_20260515155321_2354_14.jpg微信图片_20260515155023_2350_14.jpgroad traffic index line remove machine road marking removal cleaning machine-2road traffic index line remove machine road marking removal cleaning machine-3Product Parameters

road traffic index line remove machine road marking removal cleaning machine-4

Type RWXB22 Type RWXB22
Milling drum Recovery bin
Milling width 230mm Bin capacity 1m³
Milling depth 0-10mm Discharge time Lift & Dump
Milling accuracy 0.2mm Filter material Coated self-cleaning paper filter
Milling drum diameter 300mm Filter cleaning High-pressure gas reverse blowing
Engine Speed
Model YANMAR,4TNV98CT Working speed 0-25m/min
Type Diesel,four cylinder Running speed 0-8km/h
Emission National IV Size and weight
Power 53.7kW/2100rpm Outline dimensio 3850×1960×2220mm
Fuel tank volum 200L Weight 4550kg
