Concrete Spreader RWSL12

Spreader RWSL12

Technical parameters

Model	RWSL12
Engine
Model	YANMAR
Type	Diesel Engine, Liquid cooled, 4 stroke, 3-cylinder
Power	61.3kW/2500rpm
Engine oil volume	10.5L
Fuel consumption	252g/kwh
Running device
Driving	4 Hydraulic drive motor
Wheel	Antiskid tyre
Steering	2-wheel steering
Rotation	Hand controlled
Working Speed	15 square meter/min
Driving Speed	0-8km/h
Spreading
Arm length	6m
Spreading width	1.8m
Speed	Based on customers’
Spreading hopper volume	160kg
Storage hopper volume	165kg
Loading	One-Key to load
Spreading hopper sliding	200mm
Outrigger	4-leg, self-leveling
Fuel volume	135L
Hydraulic oil volume	135L
Size and Weight
Outside size	5250×2200×2500mm
Weight	7500kg
